Proto® J5546M

Proto® TorquePlus™ Socket, Standard Length, No Impact Rated, Measurement System: Metric, Square Drive, 3/4 in Drive, 46 mm Socket, 75.4 mm Overall Length, 40.8 mm Opening Depth, 45.2 mm Drive End Width, 65.3 mm Socket End Width, Ball Locking, 12 Points, 40.8 mm Bolt Clearance Depth, Alloy Steel, Satin

• Type Standard Length
• Impact Rated No
• Measurement System Metric
• Drive Type Square
• Drive Size 3/4 in
• Socket Size 46 mm
• Overall Length 75.4 mm
• Opening Depth 40.8 mm
• Drive End Width 45.2 mm
• Socket End Width 65.3 mm
• Locking Type Ball
• Number of Points 12
• Bolt Clearance Depth 40.8 mm
• Material Alloy Steel
• Finish Satin

• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners
• The TorquePlus™ configuration employs a radius corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life and allows the user to more easily turn worn, rounded, or rusted fasteners
• Ball detent design
