ARO® A212SS-024-D

Name: VALVE ALPHA SERIES (ARO-A212SS-024-D)
Brand: ARO®
SKU: ARO-A212SS-024-D
Price: 99.48 USD
Availability: InStock

4-Way Solenoid Valve, Alpha Series. 1/4" Body Ported, 2-Position, Spring Return, 24V AC/DC

$99.48

BIPN:: ARO-A212SS-024-D
Availability:: Typically Ships in 1 to 7 Days
Quantity Interval:: 1 / EA - Each

ARO® Alpha Series 4-Way, Solenoid-Actuated Air Valve. 2-Position Valve Type, Urethane Spool, Body Ported, 1/4 inch NPTF Ports, Spring Return, 24V Coil, DC Current.

Type 4-Way, 2-Position
Series Alpha
Nominal Size 1/4 in NPTF
Pressure Rating Vacuum to 150 psi
Temperature Rating 0 - 180° F
Flow Rate 50 scfm
Port Type Body Ported (NPTF)
Media Compressed Air or Inert Gas
Actuator Type Single Solenoid / Spring
Body Material Zinc
Dimensions 1-15/16 in W x 2-15/16 in L x 1-13/16 in H
Coil Voltage 24V DC
Warranty 5 Years

Zinc Valve Body, End Plate and Manifold
Bonded, precision ground spool resists wear & provides excellent shift response
Large air passages result in high flow characteristics
5-year Warranty
